Heating Boilers
For over 140 years, Hartley and Sugden have been manufacturers of steam and hot water boilers. Many famous product names have come from the Atlas Boiler Works, including Metrose Cast Iron Sectional and SCP Mild Steel hot water boilers. Boilers for Coal, Wood firing, Biomass fuels and Compact Steam boilers are a speciality of the company, with many innovative designs introduced over the years.
Today Hartley and Sugden are part of the Ormandy group of companies and market one of the most comprehensive ranges of industrial and commercial boilers in the UK. These include high efficiency low NOx outputs for single and multiple installations and condensing boilers. Cast Iron sectional boilers are also available. Most fuels are catered for and outputs range from 40 - 60000kW.
Over the years Hartley & Sugden have been suppliers to governments, local authorities, Hospital boards and major commercial organisations.
Summary of Hartley and Sugden boiler range
NORLAND Range 96 - 863 kW Stainless Steel condensing hot water boilers c/w Pressure Jet Natural Gas Burner (except the two largest sizes which fire on Pressure Jet burners. (Floor Standing only).
Metrose E Range 406 kW - 1450 kW conventional cast iron sectional hot water boilers, requiring on site assembly and suitable for firing on either Natural Gas or Light Fuel Oil using Pressure Jet burners.
Commodore Plus Range 162 - 432 kW Cast iron sectional hot water boilers of a 5pass design, suitable for firing on either oil or gas using pressure jet burners.
Optimajor Range 56 - 137 kW Cconventional cast iron sectional hot water boilers suitable for firing either oil or gas.
CALDER Range, 150 - 4000kW 3 Pass Reverse Flame Steel Shell and Tube hot water boilers, working pressure up to 5 bar ( or non standard up to 10 bar), a European design with a maximum flow temperature of 100°C. Suitable for firing either oil or gas.
SCP Range - 580 - 2930kW Traditional British 3 Pass Wet Back Steel Shell and Tube hot water boilers constructed to BS 855 for a maximum working pressure of 4.5 bar and flow temperature up to 130°C.
SCP boilers can be built for higher pressures and temperatures to the Design Code BS 2790 (PED)
Junior SCP Range, 73-580kW smaller version of the SCP but only available for working pressures and temperatures under the BS 855 Code. (max w.p 4.5 bar and max flow temp. 130°C.
SCF (Super Colifax) Range, 293 - 2930kW A traditional 3 Pass Wet Back Steel Shell and Tube hot water boilers with a conventional horseshoe (locomotive) furnace. These boilers are generally used for underfeed stoker firing and can be fuelled using most solid fuels, Coal, Wood, Pellets, Biomass etc. They can also be Oil or Gas fired if necessary.
Savile SV Steam boilers, Range 340 - 5100 kg/hr 3 Pass Reverse Flame Steel Shell and Tube boilers, built to European Standard EN 12953, for standard working pressures up to 12 bar and suitable for either Oil or Gas firing.
Metropolitan MT Steam boiler - Ranges 1700 - 17000 kg/hr Based on 3 Pass Wet Back design and built generally to EN 12953. Working pressure up to bar and suitable for either Oil or Gas firing.
We can also offer ASX, TNX and Greenox BT hot water boilers for more bespoke arrangements, these are the European equivalent to the SCP although the Greenox boiler is generally offered as the low Nox boiler, the ASX and TNX can achieve higher duties of up to 12,000kW.All three types are for gas or oil firing only.
